DS-2CE18D0T-LFS 2MP 60m Smart Hybrid light Built-in Mic Lamp Camera
New
DS-2CE18D0T-LFS
2MP Smart Hybrid Light Audio Fixed Bullet Camera
- High quality imaging with 2 MP, 1920 × 1080 resolution
- 2.8 mm, 3.6 mm and 6 mm fixed focal lens
- Up to 60 m IR distance for bright night imaging
- Up to 60 m white light distance for bright night imaging
- High quality audio with audio over coaxial cable, built-in mic
- One port for four switchable signals (TVI/AHD/CVI/CVBS）
- Water and dust resistant (IP67)
- Smart-Hybrid light, optimize your security with flexible lighting options
<h3><strong>Key Features:</strong></h3><ol><li><strong>2MP High-Quality Imaging</strong>: Provides clear and detailed 1080p full HD video output, ensuring a better visual experience.</li><li><strong>Versatile Lens Options</strong>: Offers 2.8mm, 3.6mm, and 6mm fixed focal lengths to suit various surveillance needs.</li><li><strong>Enhanced Night Vision</strong>: Equipped with up to 60m IR (infrared) and white light distances, allowing bright imaging even in low light or dark conditions.</li><li><strong>Audio Over Coaxial Cable</strong>: Built-in microphone delivers high-quality audio, enhancing video evidence with sound recording.</li><li><strong>Four Switchable Signal Modes</strong>: Supports TVI, AHD, CVI, and CVBS formats, making it versatile for integration with various DVRs and older systems.</li><li><strong>Smart Hybrid Light Technology</strong>: Adapts lighting based on surveillance needs, offering both IR and white light for optimized visual clarity.</li><li><strong>IP67 Rating</strong>: Ensures protection against water and dust, making the camera suitable for outdoor and harsh weather conditions.</li></ol><h3><strong>Key Benefits:</strong></h3><ol><li><strong>Crystal Clear Imaging</strong>: The 2MP resolution and choice of focal lengths ensure that every detail is captured, enabling effective monitoring and evidence collection.</li><li><strong>Optimized Night Surveillance</strong>: With a long-range IR and white light distance, you can monitor large outdoor areas effectively at night.</li><li><strong>Flexible Signal Compatibility</strong>: The four switchable signal modes offer flexibility in upgrading or expanding surveillance systems without compatibility issues.</li><li><strong>Audio Support for Enhanced Security</strong>: The built-in mic allows for real-time monitoring with sound, providing better context and understanding of events.</li><li><strong>Durability and Reliability</strong>: The IP67 rating ensures the camera’s durability in tough outdoor environments, reducing maintenance costs.</li><li><strong>Adaptive Lighting for Efficient Security</strong>: The Smart Hybrid Light feature allows for customizable and energy-efficient lighting, improving security monitoring efficiency.</li></ol>
Camera:
- Image Sensor: 2 MP CMOS
- Max. Resolution: 1920 (H) × 1080 (V)
- Min. Illumination: 0.01 Lux @ (F2.0, AGC ON); 0 Lux with white light
- Shutter Time: PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
- Day & Night: ICR (Infrared Cut Filter Removable)
- Angle Adjustment:
- Pan: 0 to 360°
- Tilt: 0 to 180°
- Rotation: 0 to 360°
- Signal System: PAL/NTSC
Lens:
- Type: Fixed focal lens, available in 2.8 mm, 3.6 mm, and 6 mm
- Focal Length & FOV:
- 2.8 mm: Horizontal FOV: 101°, Vertical FOV: 56°, Diagonal FOV: 118°
- 3.6 mm: Horizontal FOV: 78°, Vertical FOV: 42°, Diagonal FOV: 92°
- 6 mm: Horizontal FOV: 49.2°, Vertical FOV: 28.3°, Diagonal FOV: 56.1°
- Lens Mount: M12
Illuminator:
- Supplement Light Type: White Light and IR
- Supplement Light Range:
- IR Distance: Up to 60 m
- White Light Distance: Up to 60 m
Image:
- Image Settings: Anti-Banding, Brightness, Sharpness, Smart IR
- Frame Rate:
- TVI: 1080P @ 30 fps / 25 fps
- AHD: 1080P @ 30 fps / 25 fps
- CVI: 1080P @ 30 fps / 25 fps
- CVBS: PAL/NTSC
- Day/Night Mode: Auto/Color/Black & White (B/W)
- Wide Dynamic Range (WDR): Digital WDR
- Image Enhancement: DWDR, BLC (Backlight Compensation), HLC (Highlight Compensation), Global
- White Balance: Auto/Manual
- AGC (Automatic Gain Control): Yes
Interface:
- Video Output: Switchable TVI/AHD/CVI/CVBS
General:
- Power: 12 VDC ± 25%, max. 9.8 W (Recommended: Use one power adapter per camera)
- Material:
- Front Cover: Metal
- Main Body: Plastic
- Dimension: 192.6 mm × 178.3 mm × 71 mm (7.58" × 7.02" × 2.8")
- Weight: Approx. 738 g (1.63 lb.)
- Operating Condition: -40 °C to 60 °C (-40 °F to 140 °F); Humidity: 90% or less (non-condensation)
Communication:
- Protocol: HIKVISION-C
- Language: English
Approvals & Protections:
- Protection: IP67 (Water and Dust Resistant)
